SDS Plus Drill Bits (Hammer Drill)

SMT SDS SERIES | SDS Plus Drill Bits

An elite lineup of high-impact rotary hammer drill bits engineered with standardized SDS Plus slotted shanks. Forged to handle continuous stress in heavy-duty brickwork, tough masonry channels, and reinforced concrete surfaces, the optimized flute tracks ensure flawless dust removal and zero axial slip.

Shank Type: SDS Plus System

Application: Concrete / Stone

Diameter Matrix: 5mm to 32mm Sizes

Reach Scale: Up to 600mm Depth

✔ Engineered specifically to endure heavy pneumatic hammer pounding without shaft breakage.
✔ Entirely pre-mapped for wholesale storage deployment and professional B2B product catalogs.

Compare

Add to wishlist

Description

HEAVY-DUTY MASONRY IMPACT LINE

SDS PLUS DRILL BITS SERIES

Industrial Cross-Flute Slotted Drive System Hammer Drill Bits

Drive structural power into tough construction matrices seamlessly with the advanced reinforcing layout of the Industrial SDS PLUS Drill Bit Series. Forged from optimized premium steel variants engineered to endure structural impact loads and finished with a durable treatment layer, these professional-grade slotted shanks lock effortlessly into pneumatic rotary hammer chucks. Optimized primarily for rigorous concrete drilling, brickwork masonry structural tasks, natural stones, and thick composite panels, the specialized deep spiral geometry sweeps debris rapidly away from the cutting tip to reduce friction binding. Arranging an extensive dimension spectrum from compact 5mm x 110mm starter variants up to massive deep-reach 25mm x 600mm heavy-duty sizes, this elite tool matrix provides complete logistical support for engineering sites, mechanical distribution channels, and volume commercial procurement hubs.

Engineered Benefits

✓ Slotted Drive System Shank: Standardized SDS Plus dual-groove configuration prevents chunk slippage, converting raw machine impact force entirely into forward axial drilling momentum.

✓ High-Velocity Dust Clearance Flutes: Wide-track double spiral design handles dense stone grit instantly, cooling the tool head to extend carbide lifespan under continuous operational loads.

✓ Commercial Packaging Breakdown: Packaged carefully into structured internal cartons (10-piece sets for small gauges and standalone single sleeves for deep-reach lengths) to perfectly suit bulk dealer networks.

Technical Product Matrix (Size & Packaging Speeds)

No.	Size Variant (mm)	Per Internal Box	Per Master Carton
01	5 x 110	10 Pcs	500 Pcs
02	6 x 110	10 Pcs	500 Pcs
03	6 x 160	10 Pcs	400 Pcs
04	8 x 160	10 Pcs	300 Pcs
05	10 x 160	10 Pcs	300 Pcs
06	12 x 160	10 Pcs	300 Pcs
07	14 x 160	10 Pcs	200 Pcs
08	16 x 160	10 Pcs	200 Pcs
09	18 x 210	10 Pcs	100 Pcs
10	20 x 210	10 Pcs	100 Pcs
11	22 x 210	10 Pcs	100 Pcs
12	25 x 210	10 Pcs	60 Pcs
13	10 x 350	01 Pc	170 Pcs
14	12 x 350	01 Pc	150 Pcs
15	14 x 350	01 Pc	100 Pcs
16	16 x 350	01 Pc	100 Pcs
17	18 x 350	01 Pc	70 Pcs
18	20 x 350	01 Pc	60 Pcs
19	22 x 350	01 Pc	40 Pcs
20	25 x 350	01 Pc	30 Pcs
21	28 x 350	01 Pc	30 Pcs
22	30 x 350	01 Pc	25 Pcs
23	32 x 350	01 Pc	25 Pcs
24	12 x 460	01 Pc	70 Pcs
25	14 x 460	01 Pc	70 Pcs
26	16 x 460	01 Pc	70 Pcs
27	18 x 460	01 Pc	50 Pcs
28	20 x 460	01 Pc	50 Pcs
29	22 x 460	01 Pc	30 Pcs
30	25 x 460	01 Pc	25 Pcs
31	30 x 460	01 Pc	20 Pcs
32	12 x 600	01 Pc	70 Pcs
33	14 x 600	01 Pc	70 Pcs
34	16 x 600	01 Pc	50 Pcs
35	18 x 600	01 Pc	50 Pcs
36	20 x 600	01 Pc	50 Pcs
37	22 x 600	01 Pc	20 Pcs
38	25 x 600	01 Pc	25 Pcs

Core Series Specifications:

• Tool Segment: Rotary Hammer Impact Bit • Material Composition: High Speed Steel Core • Shank Layout: SDS Plus Slotted Drive Profile • Color Coat: Industrial Silver (White) • Core Applications: Brickwork Masonry, Reinforced Concrete, Building Blocks, Plastics & Tough Stones • Length Scale: Standard Deep-Reach Ratio Layout
